Flagship · Heavy Load
Heavy-Duty
Power Pack.
Custom battery packs for cordless power tools — engineered for shock, heat and zero throttling under sustained load.
Technical
Specifications
- Nominal voltage
- 18 V / 20 V Max (5S)
- Cell type
- 21700 high-drain Li-ion
- Configuration
- 5S1P – 5S2P (custom)
- Capacity range
- 2.0 – 6.0 Ah
- Continuous discharge
- up to 40 A
- Cycle life
- ≥ 800 cycles @ 80% DoD
- Ingress protection
- IP54 housing
- Operating temp
- −10 °C to 60 °C
- BMS
- OCP / OTP / short-circuit protection
- Housing
- Impact-resistant PA6-GF30 shell
Where it fits
Applications
Cordless Drills & Drivers
Stable voltage through torque spikes — no mid-task throttling.
Angle Grinders & Saws
High continuous discharge for sustained high-RPM cutting.
Outdoor & Garden Tools
Sealed IP54 housing for dust, debris and damp jobsites.
Fast-Charge Docks
Balanced cells and thermal headroom for rapid recharge cycles.
Process
Engineering & Testing
- 01
Vibration & Shock
MIL-STD random vibration plus repeated impact.
- 02
Drop Test
1.5 m drop onto concrete, every face.
- 03
Overcurrent & Short
Hard-short and over-discharge abuse cleared by the BMS.
- 04
Thermal Cycling
−10 °C ⇄ 60 °C soak with capacity verification.
Questions
FAQ
Can you match my existing tool's battery interface?
Yes — we reverse-engineer the slide/latch and terminal layout, or work from your CAD/sample to produce a drop-in compatible pack.
What MOQ applies for a custom housing?
Tooling-free assembly starts at low volumes; custom-molded housings become economical from ~1,000 units. We quote both routes.
Do packs ship with the BMS pre-configured?
Every pack ships with a calibrated BMS — protection thresholds, fuel-gauge and optional cell-balancing tuned to your discharge profile.
Which certifications are included?
UN38.3 transport, CE and RoHS as standard, with MSDS provided. Additional marks (UL, KC) on request.
